AHS40-01
Handheld transmitter | 1-channel | 40.685MHz | AM | key colour: red
Availability
Part number
02001100
The standard AHS40-01 (formerly DX40) handheld transmitter has one send button and works with the frequency of 40.685MHz in AM technology. The coding is carried out via a 10-pin coding switch. It is possible to have your company logo imprinted and for the keys to have various special colours, by arrangement.
- LED for battery and transmission control
- 1,024 coding possibilities via coding switch, LinearCode
- Compatible with our 12-bit AM radio receivers
- Exempt from registration and from charges! Europe-wide approval according to ETS 300220
| Dimensions | 105 x 60 x 23mm |
|---|---|
| Channels | 1 channel |
| Operat. temperature | -20°C to +60°C |
| Coding | linear |
| Frequency | 40,685MHz |
| Weight | 135g |
| Channels | 1 |
| Modulation mode | AM |
| Product type | Handheld transmitter |
| Operating range | up to 100m |
