AHS40-05
Handheld transmitter | 10-channel | 40.685MHz | AM | key colour: red
Availability
Part number
02004900
The standard AHS40-05 (formerly DX40) handheld transmitter has one send button and a BCD switch to change between 10 different channels. It works with a frequency of 40.685MHz in AM technology. The coding is carried out via a 10-pin coding switch.
It is possible to have your company logo imprinted and for the keys to have various special colours, by arrangement.
- Multi-channel function for operating up to 10 components within one reception area (e.g. 10 gates, 10 lights, 10 blinds)
- LED for battery and transmission controle
- Compatible with our 12-bit AM radio receivers
- Exempt from registration and from charges! Europe-wide approval according to ETS 300220
| Dimensions | 105 x 60 x 23mm |
|---|---|
| Channels | More than 4 |
| Operat. temperature | -20°C to +60°C |
| Coding | linear |
| Frequency | 40,685MHz |
| Weight | 140g |
| Channels | more than 4 |
| Modulation mode | AM |
| Product type | Handheld transmitter |
| Operating range | up to 100m |
