S8Q-868A04K00
High-gloss handheld transmitter | 4-channel | 868.3MHz | AM | KeeLoq | incl. wall mount
Availability
Part number
02008800
The S8Q-868A04K00 has 4 send buttons and works with 868.3MHz and AM modulation mode. Each time it is actuated, a new code is calculated.
The transmitter must be taught-in once electronically on the radio receiver (each button to have effect).
An individual design of the front foil and a customer-specific coding are possible after consultation.
The Quick Learn function allows additional transmitters or transmitter keys to be taught-in in conjunction with Q-series receivers, without direct access to the receiver.
- Compatible with our 868.3MHz AM radio receivers
- 4 send buttons
- KeeLoq coding (Dickert Manufacturercode)
- QuickLearn distance learning
- Blue LED for battery and transmission control
- Exempt from registration and from charges! Approval according to ETS 300220
| Dimensions | 64 x 35 x 11mm |
|---|---|
| Channels | 4 channel |
| Operat. temperature | -20°C to +60°C |
| Coding | KeeLoq |
| Frequency | 868,3MHz |
| Weight | 22g |
| Channels | 4 |
| Modulation mode | AM |
| Product type | Handheld transmitter |
| Operating range | up to 75m |
